2011-2019
Front 3/4Click to expand
The first turbocharged-only 3 Series. The F30 embraced forced induction across the entire range, ending the naturally aspirated era that defined the nameplate.
History
The F30 was lighter than the E90 thanks to increased aluminum use, yet larger in every dimension. The 335i's N55 twin-scroll turbo six produced 306 hp with better fuel economy than the E90 330i it replaced.
Timeline
2011Production begins
2019Production ends
Production & Heritage
Production Total3,100,000
DesignerChristopher Weil
Production Period2011-2019
Estimated Value$12K-$28K
Value estimates are editorial assessments based on recent auction results and market trends.
Technical Specifications
Engine2.0L Inline-4 Turbo (N20)
Power245 hp @ 5,000 rpm
Torque350 Nm
0-60 mph5.6 sec
Top Speed250 km/h
Transmission8-speed automatic (ZF)
DrivetrainRWD
Weight1,480 kg
Drag CoefficientCd 0.26
BodySteel/aluminum monocoque
Engine Details
Engine CodeN20B20
Displacement2.0L (1,997 cc)
Bore x Stroke84 x 90 mm
Compression10
Valves16
Fuel SystemDirect injection (TVDI) with twin-scroll turbocharger
Engine ManagementBosch MEVD17.2.4
Performance
0-100 km/h5.9 sec
0-60 mph5.6 sec
Top Speed250 km/h
Fuel Economy6.4 l/100km combined
Weight-to-Power6.0 kg/hp
Dimensions
Length4,624 mm
Width1,811 mm
Height1,429 mm
Wheelbase2,810 mm
Chassis & Suspension
Front SuspensionDouble-joint spring strut (MacPherson-type)
Rear SuspensionFive-link independent
Front BrakesVentilated discs 312mm
Rear BrakesSolid discs 300mm
SteeringElectric power steering (EPS)
Tires225/45 R18
Wheels8J x 18
Stability SystemsDSC incl. ABS, CBC, DTC, DBC
Drivetrain
Gear Ratios4.714 / 3.143 / 2.106 / 1.667 / 1.285 / 1.000 / 0.839 / 0.667 (ZF 8HP45)
Final Drive3.231
Capacity
Fuel Tank60 L
Trunk Volume480 L
Doors4
Seats5
Source: BMW AG / Wikipedia
