2011-2019
Front 3/4Click to expand
The second-generation 1 Series — still rear-wheel drive, still offering a straight-six, and still the enthusiast's choice in the premium compact segment.
History
The M135i with its N55 single-turbo six producing 326 hp was the hot hatch BMW never officially called one. It could hit 60 mph in 4.7 seconds — faster than an E46 M3.
Timeline
2011Production begins
2019Production ends
Production & Heritage
Production Total1,100,000
DesignerNicolas Huet
Production Period2011-2019
Estimated Value$6K-$18K
Value estimates are editorial assessments based on recent auction results and market trends.
Technical Specifications
Engine3.0L Inline-6 Turbo (N55)
Power326 hp @ 5,800 rpm
Torque450 Nm
0-60 mph4.9 sec
Top Speed250 km/h
Transmission8-speed automatic
DrivetrainRWD
Weight1,420 kg
Drag CoefficientCd 0.33
BodySteel unibody monocoque
Engine Details
Engine CodeN55B30M0
Displacement3.0L (2,979 cc)
Bore x Stroke84 x 89.6 mm
Compression10.2
Valves24
Fuel SystemDirect injection, twin-scroll turbocharger
Engine ManagementBosch MEVD17.2
Performance
0-100 km/h5.1 sec
0-60 mph4.9 sec
Top Speed250 km/h
Fuel Economy8.0 l/100km combined
Weight-to-Power4.4 kg/hp
Dimensions
Length4,340 mm
Width1,765 mm
Height1,411 mm
Wheelbase2,690 mm
Chassis & Suspension
Front SuspensionMacPherson struts
Rear SuspensionMulti-link
Front BrakesVentilated discs
Rear BrakesSolid discs
SteeringRack and pinion, electric power-assisted (EPS)
Tires (Front)225/40 R18
Tires (Rear)245/35 R18
Wheels8J x 18 front, 8.5J x 18 rear
Stability SystemsABS, DSC, DTC, CBC
Drivetrain
Gear Ratios1st 4.11, 2nd 2.32, 3rd 1.54, 4th 1.18, 5th 1.00, 6th 0.85
Final Drive3.08
Capacity
Fuel Tank52 L
Trunk Volume360 L
Doors5
Seats5
Source: BMW AG Press Release, Wikipedia
