2014-2020
Front 3/4Click to expand
The four-door 4 Series — a liftback coupe that combined the F32's style with near-3 Series practicality. The Gran Coupe body style became Audi A5 Sportback's main rival.
History
The F36 Gran Coupe proved that a swoopy roofline and a practical hatchback weren't mutually exclusive. The 440i's B58 turbo six delivered 326 hp with refined smoothness.
Timeline
2014Production begins
2020Production ends
Production & Heritage
Production Total350,000
DesignerChristopher Weil
Production Period2014-2020
Estimated Value$12K-$25K
Value estimates are editorial assessments based on recent auction results and market trends.
Technical Specifications
Engine2.0L Inline-4 Turbo (B48)
Power252 hp @ 5,200 rpm
Torque350 Nm
0-60 mph5.6 sec
Top Speed250 km/h
Transmission8-speed automatic (ZF)
DrivetrainRWD
Weight1,555 kg
Drag CoefficientCd 0.27
BodySteel/aluminum monocoque
Engine Details
Engine CodeB48B20
Displacement2.0L (1,998 cc)
Bore x Stroke82 x 94.6 mm
Compression10.2
Valves16
Fuel SystemDirect injection with twin-scroll turbocharger, Valvetronic IV, Double VANOS
Engine ManagementBosch MEVD17.2.9
Performance
0-100 km/h5.9 sec
0-60 mph5.6 sec
Top Speed250 km/h
Fuel Economy6.2 l/100km combined
Weight-to-Power6.2 kg/hp
Dimensions
Length4,638 mm
Width1,825 mm
Height1,389 mm
Wheelbase2,810 mm
Chassis & Suspension
Front SuspensionDouble-joint spring strut (MacPherson-type)
Rear SuspensionFive-link independent
Front BrakesVentilated discs 312mm
Rear BrakesSolid discs 300mm
SteeringElectric power steering (EPS)
Tires (Front)225/45 R18
Tires (Rear)255/40 R18
Wheels8J x 18 front / 8.5J x 18 rear
Stability SystemsDSC incl. ABS, CBC, DTC
Drivetrain
Gear Ratios4.714 / 3.143 / 2.106 / 1.667 / 1.285 / 1.000 / 0.839 / 0.667 (ZF 8HP45)
Final Drive3.231
Capacity
Fuel Tank60 L
Trunk Volume480 L
Doors4
Seats5
Source: BMW AG / Wikipedia
