2013-2021
Front 3/4Click to expand
The spiritual successor to the 2002 — a compact, rear-wheel-drive coupe with a turbocharged six. The last of its kind before BMW moved the 2 Series to front-wheel drive.
History
The M235i and later M240i offered M-adjacent performance in a compact package. The F22 was the last RWD 2 Series coupe — its successor switched to a front-drive platform, making the F22 the end of an era.
Timeline
2013Production begins
2021Production ends
Production & Heritage
Production Total245,000
DesignerNicolas Huet
Production Period2013-2021
Estimated Value$18K-$35K
Value estimates are editorial assessments based on recent auction results and market trends.
Technical Specifications
Engine3.0L Inline-6 Turbo (N55)
Power326 hp @ 5,800 rpm
Torque450 Nm
0-60 mph4.8 sec
Top Speed250 km/h
Transmission6-speed manual
DrivetrainRWD
Weight1,520 kg
Drag CoefficientCd 0.29
BodySteel unibody monocoque
Engine Details
Engine CodeN55B30M0
Displacement3.0L (2,979 cc)
Bore x Stroke84 x 89.6 mm
Compression10.2
Valves24
Fuel SystemDirect injection, twin-scroll turbocharger
Engine ManagementBosch MEVD17.2
Performance
0-100 km/h5 sec
0-60 mph4.8 sec
Top Speed250 km/h
Fuel Economy7.8 l/100km combined
Weight-to-Power4.7 kg/hp
Dimensions
Length4,454 mm
Width1,774 mm
Height1,408 mm
Wheelbase2,690 mm
Chassis & Suspension
Front SuspensionMacPherson struts
Rear SuspensionMulti-link
Front BrakesVentilated discs 340mm
Rear BrakesVentilated discs 345mm
SteeringRack and pinion, electric power-assisted (EPS)
Tires (Front)225/40 R18
Tires (Rear)245/35 R18
Wheels8J x 18 front, 8.5J x 18 rear
Stability SystemsABS, DSC, DTC, CBC
Drivetrain
Gear Ratios1st 4.11, 2nd 2.32, 3rd 1.54, 4th 1.18, 5th 1.00, 6th 0.85
Final Drive3.08
Capacity
Fuel Tank52 L
Trunk Volume390 L
Doors2
Seats4
Source: BMW AG Press Release, Wikipedia
