1966-1985
Front 3/4Click to expand
Italy's MX-5 — a Pininfarina-designed roadster that brought affordable open-top Italian motoring to the world. Produced for almost 20 years.
History
Designed by Tom Tjaarda at Pininfarina, the 124 Spider was Fiat's affordable answer to the British roadsters. Its twin-cam engine was more advanced than anything from MG or Triumph. It was hugely popular in the US, where most of the 198,000 units were sold.
Timeline
1966Production begins
1985Production ends
Production & Heritage
Production Total198,000
DesignerTom Tjaarda (Pininfarina)
Production Period1966-1985
Estimated Value$15K-$35K
Value estimates are editorial assessments based on recent auction results and market trends.
Technical Specifications
Engine1.8L Inline-4 DOHC (132 A1)
Power118 hp @ 6,200 rpm
Torque137 Nm
0-60 mph10.5 sec
Top Speed180 km/h
Transmission5-speed manual
DrivetrainRWD
Weight1,035 kg
BodySteel unibody, Pininfarina body
Engine Details
Engine CodeFiat DOHC 1608cc
Displacement1.8L (1,756 cc)
Bore x Stroke80 x 80 mm
Compression8.9
Fuel SystemWeber 34 DHS dual-throat carburetor
Performance
0-100 km/h11 sec
0-60 mph10.5 sec
Top Speed180 km/h
Weight-to-Power8.8 kg/hp
Dimensions
Length3,980 mm
Width1,630 mm
Height1,245 mm
Wheelbase2,280 mm
Chassis & Suspension
Front SuspensionDouble wishbone, coil springs, anti-roll bar
Rear SuspensionLive axle, coil springs, Panhard rod
Front BrakesDisc
Rear BrakesDrum
SteeringWorm and roller
Tires165 SR 14
Capacity
Fuel Tank42 L
Trunk Volume150 L
Doors2
Seats2
Source: Fiat / Wikipedia
