2005-2011
Front 3/4Click to expand
The last naturally aspirated 3 Series. The E90 marked the transition from analog purity to turbocharged efficiency — the end of an era.
History
The E90 was the first 3 Series with run-flat tires and electric steering assist. The 335i introduced the N54 twin-turbo six that previewed BMW's forced-induction future. The M3's V8 was a controversial but thrilling departure.
Timeline
2005Production begins
2011Production ends
Production & Heritage
Production Total3,246,000
DesignerAdrian van Hooydonk
Production Period2005-2011
Estimated Value$8K-$25K
Value estimates are editorial assessments based on recent auction results and market trends.
Technical Specifications
Engine3.0L Inline-6 (N52)
Power258 hp @ 6,600 rpm
Torque300 Nm
0-60 mph5.8 sec
Top Speed250 km/h
Transmission6-speed manual
DrivetrainRWD
Weight1,460 kg
Drag CoefficientCd 0.3
BodySteel unibody monocoque with aluminum front end
Engine Details
Engine CodeN52B30
Displacement3.0L (2,996 cc)
Bore x Stroke85 x 88 mm
Compression10.7
Valves24
Fuel SystemSequential multipoint fuel injection
Engine ManagementSiemens MSV70 (Valvetronic II)
Performance
0-100 km/h6.3 sec
0-60 mph5.8 sec
Top Speed250 km/h
Fuel Economy8.7 l/100km combined
Weight-to-Power5.7 kg/hp
Dimensions
Length4,520 mm
Width1,817 mm
Height1,421 mm
Wheelbase2,760 mm
Chassis & Suspension
Front SuspensionDouble-pivot MacPherson struts, aluminum components
Rear SuspensionFive-link multi-link
Front BrakesVentilated discs 330mm
Rear BrakesVentilated discs 336mm
SteeringRack and pinion, hydraulic power-assisted
Tires225/45 R17
Wheels8J x 17
Stability SystemsABS, DSC, DTC, CBC, DBC
Drivetrain
Gear Ratios1st 4.35, 2nd 2.50, 3rd 1.67, 4th 1.23, 5th 1.00, 6th 0.85 (GS6-37BZ)
Final Drive3.23
Capacity
Fuel Tank63 L
Trunk Volume460 L
Doors4
Seats5
Source: BMW AG / Wikipedia
