2009-2015
Front 3/4Click to expand
What makes it iconic
BMW's smallest SUV and the entry point to the X range. The E84 was rear-wheel-drive based — a layout abandoned in its successor.
History
The E84 X1 was essentially a raised 3 Series Touring on a rear-drive platform, giving it handling characteristics unusual for a compact SUV. The xDrive28i's turbocharged four was the sweet spot.
Timeline
2009Production begins
2015Production ends
Production & Heritage
Production Total303,626
DesignerPierre Leclercq
Production Period2009-2015
Estimated Value$5K-$15K
Value estimates are editorial assessments based on recent auction results and market trends.
Technical Specifications
Engine2.0L Inline-4 Turbo (N20)
Power245 hp @ 5,000 rpm
Torque350 Nm
0-60 mph5.7 sec
Top Speed240 km/h
Transmission8-speed automatic
DrivetrainAWD
Weight1,550 kg
Drag CoefficientCd 0.33
BodySteel unibody
Engine Details
Engine CodeN20B20
Displacement2.0L (1,997 cc)
Bore x Stroke84 x 90.1 mm
Compression10
Valves16
Fuel SystemHigh-pressure direct injection (HPI), piezo injectors
Engine ManagementBosch MEVD17.2, Valvetronic, Double VANOS
Performance
0-100 km/h6.1 sec
0-60 mph5.7 sec
Top Speed240 km/h
Fuel Economy8.5 l/100km combined
Weight-to-Power6.3 kg/hp
Dimensions
Length4,454 mm
Width1,798 mm
Height1,545 mm
Wheelbase2,760 mm
Chassis & Suspension
Front SuspensionMacPherson strut, coil springs, anti-roll bar
Rear SuspensionMulti-link, coil springs, anti-roll bar
Front BrakesVentilated disc
Rear BrakesVentilated disc
SteeringRack-and-pinion, electric power-assisted
Tires225/50 R17
Wheels17-inch alloy
Stability SystemsDSC, DTC, ABS, CBC, DBC
Drivetrain
Gear Ratios4.714 / 3.143 / 2.106 / 1.667 / 1.285 / 1.0 / 0.839 / 0.667 (8-speed auto)
Final Drive3.15
Capacity
Fuel Tank63 L
Trunk Volume420 L
Doors5
Seats5
Source: BMW AG / Wikipedia
